• EdgeVac Sensors
Use /
once a year. To start process, press the Calibrate button.
• Tank Pressure
Check the box only if the planter is equipped with tank pressure sensor. Calibrate the sensor once a year.
To start process, press Calibrate button.

EdgeVac

Use / to enter the number of EdgeVac® sensors.
Calibrate EdgeVac sensors once a year. To start process, press Calibrate button. For more information,
see
"KINZE EdgeVac Calibration" on page 215

KINZE Sensor Configuration

Seed Monitor
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > your
specific configuration > Setup (wrench) button > Seed Monitor button > Sensor Configuration button
Sensor Configuration
Item
Rear Section
Row 1
Row 2
Row 3
Row 4
Row 5
Row 6
Row 7
Row 8
Row 9
Row 10
Shows the Sensor Information screen. For more information, see
Note: After initial configuration of the KINZE Planter Monitor, complete the Sensor Muxbus Detection process.
For more information, see

Muxbus Sensor Detection

After initial configuration of the KINZE Planter Monitor, complete the Sensor Muxbus Detection process.
This process allows the muxbus to detect each sensor on the planter. In order for the display to show the
correct Planter Monitor information, complete the detection process for each muxbus sensor.
Note: Be sure that all sensors are unplugged before beginning the process. If any sensors are plugged in,
the Muxbus Detection process will abort. If this occurs, unplug all sensors and retry procedure.
Ag Leader PN 4002083 Rev. N
to enter the number of EdgeVac® sensors on the planter. Calibrate EdgeVac sensors
.
Configuration
Sensor Configuration
Status
Install
OK
Remove
OK
Revive
OK
OK
Ignore
OK
OK
View
OK
OK
OK
OK
"Muxbus Sensor Detection" on page
Select Your Specific
Configuration
The Sensor Configuration screen is for system
maintenance of the KINZE Population Monitor.
• The Install button installs a row sensor.
• Remove button
Removes the highlighted sensor of any type.
• Revive button
Allows the display to reattempt communication with the
highlighted sensor of any type.
• Ignore button
Tells the display to cease communications with a row
sensor.
• View button
"Sensor Information" on page 213
211.
