Ag Leader Integra Display Operator's Manual page 134

Press: Home button > Setup (wrench) button > GPS button > Receiver Setup (wrench) button > General
> OmniSTAR (Differential Source drop-down menu) > Setup (wrench) button
Note: If using the GPS 2500 receiver, see
OmniSTAR Setup
Serial Number
0224019369
Differential Source
VBS
HP/XP
HP/XP with VBS Backup
Fast Restart
Note: The use of OmniSTAR® differential requires purchase of a subscription from OmniSTAR. Settings
related to using satellite differential correction vary based upon your geographic location. Setup details are
explained on the following pages. More specific information can be obtained by contacting OmniSTAR.
• Serial Number/OmniSTAR User ID
This box shows the serial number of your receiver. It may also display your OmniSTAR User ID.
Note: You will need to know this number when contacting OmniSTAR in order to set up the receiver.
• Differential Source
The choices include VBS, HP/XP, and HP/XP with VBS backup. These three options are described below.
- VBS - OmniSTAR VBS is a "sub-meter" level of service.
- HP/XP - The OmniSTAR XP service is more accurate than VBS, but slightly less accurate than HP. The
OmniSTAR HP (High Performance) service is the most accurate of the three options.
- HP/XP with VBS backup - If this option is chosen, and you lose your HP/XP signal, your receiver will
automatically switch to VBS.
• Frequency
In the Frequency drop-down list box, select the geographic region where you are located. If you wish to
enter a Custom Frequency, select Custom. Then enter the frequency number in the text box below.
Note: The display does not come with custom frequency numbers. Enter a number only if directed to by
OmniSTAR.
• Baud Rate
The baud rate represents the speed at which your receiver obtains information from the satellite.
Note: You should always keep the baud rate set at 1200 unless directed by OmniSTAR or Technical Support.
118
"OmniSTAR Settings — GPS 2500" on page
Provider Settings
Frequency Central USA (MSV-C)
Custom
1557.835
Frequency
Baud Rate 1200
119.
Firmware Version 6.0
