KINZE D
ISPLAY
38.4
ac
120 %
100 %
Planter Drives (rpm)
80 %
1 60 %
2 3
77 72 72
2
Press button shown below to advance to the next button.
Shaft Speed
Shaft Speed
The speed of the planter drive shafts, in RPM.
Outer Left 60 rpm
Inner Left 60 rpm
SDS - The speed of the planter seed delivery system (auger), in RPM.
EdgeVac Level - Measure of seed meter vacuum. This measurement, shown in inches of water, is
displayed for each vacuum fan.
Pneumatic Down Pressure - Measure of down force the air bag places on the row unit.
Magnetic Pickup - Speed registered according to the magnetic pickup.
Tank Weight - The weight of seed in each tank.
Tank Area Left
The number of acres (hectares) that can be planted with the amount of seed remaining in the tanks.
Tank Pressure
The air pressure level for the Air Seed Delivery (ASD) system.
Down Force - Measure of force on gauge wheel and force being applied to row unit.
Ag Leader PN 4002083 Rev. N
I E
TEMS ON QUIPMENT
546R1
30000
30000
Population: 30000 sds/ac Spacing 30 in
6 14 16
4 8 10 12 18 20 22
T
AB
The left-hand side of the Map screen's
5.0
mph
Equipment Tab includes a number of
1
sds/ac
30000
display items that will vary depending
2
upon the particular KINZE Planter
29000
Monitor Module configuration.
Flow: 10560 sds/min
Applied: 9064.0 sds
Area: 0.33 ac
Swath: 40 ft 0 in 100%
Settings
Shaft Speed
Outer Left 1
Inner Left
24
P
LANTING
217
