A message displays, stating "Seed Meter Prime in Progress." While this message displays, the seed
meter will turn one (and only one) revolution automatically. When complete, return to the Seed Rate
Planter Control screen.
C
ALIBRATING
The Meter Calibration number allows the seed meter to communicate the correct seed population to the
display. Assuming the Controller Settings are correct for the seed rate, this Meter Calibration number,
which is based on the number of cells on the seed meter, should not need to be adjusted. However, you
may wish to recalibrate after changing seed types and treatments. Recalibrate if the as-applied seed
rate does not match the population shown on the planter monitor.
Notes:
• The seed rate meter calibration does not recalibrate any previously-logged planting data.
• This recalibration number applies to a specific crop type, i.e., corn. Normally, there is no need to
recalibrate when switching varieties within the same crop type.
• Make sure seed meter is primed. For more information, See
Settings
Press: Map button > Settings button > Planter Drives tab > Calibrate button
or
Planter Drives (rpm)
1
70
Press: Map button > Meter RPM button > Planter Drives > Calibrate button
1. Acknowledge the Warning
Acknowledge this warning by pressing
2. Select Drive to Calibrate
The Meter Calibration Wizard appears. Select the drive to calibrate. Press
3. Enter Simulated Ground Speed
Enter the simulated ground speed for the calibration procedure. Press
4. Enter Simulated Target Rate
Enter the simulated target rate of the calibration procedure. Press
5. Press Start
Press the green-colored Start button to begin dispensing the seed.
6. Dispensing Seed
The seed meter turns for five revolutions. As the seed meter dispenses seed, the button will change its color
to red, and a message displays that the seed dispensation is in process.
180
S R
EED ATE
Planter Drives
Planter Drives
.
M
ETERS
"Priming Seed Rate Meters"
Calibrate
Calibrate
above.
to continue.
to continue.
to continue.
