Boom Height Control Options Screen

Mode: Crop
15.9
Boom Height Control Options
Crop Mode
Sensitivity
B H
OOM EIGHT
The Boom Height Diagnostics screen shows all data for individual sensors, including Height, Roll and
Temperature.
To go to the Boom Height Diagnostics screen, press on the Device Information button. At
the Devices screen, highlight the item marked NORAC UC5 then press the Diagnostics
button.
Boom Height Diagnostics
General
Control Mode
Target Height (cm)
Remote Switch
Location Serial
Left Outer 100
1
Left Inner
2 103
3 Main Lift 101
Right Inner 104
4
5 Right Outer 102
6 Boom Frame
105
Ag Leader PN 4002083 Rev. N
Target Height: 12 in
8.4 8.4
Target Height
12
5
D
IAGNOSTICS
Boom Control State
Crop Left
30.4
Center
- Right
Roll
Height / Roll
91 cm 21.1 C
21.1 C
89 cm
102 cm 21.1 C
21.1 C
84 cm
81 cm
21.1 C
8.0 N/A
Pressing the Boom Height Control
Sensitivity: 5
Options button (A) opens the Boom
Height Control Options screen (B). At
this screen, you can adjust the boom's
Mode, Sensitivity and Target Height.
50 F
• Mode
The drop-down menu is where you can choose
one of two modes:
- In Soil Mode, the UC5 controls boom height
relative to the distance from the soil.
- In Crop Mode, the UC5 controls boom height
relative to distance from the crop canopy.
• Sensitivity
Adjusts the boom response. Higher values
make the height control more responsive;
settings range from 0-10.
• Target Height
User-defined boom height in relation to the
selected control mode.
The NORAC UC5 Diagnostics screen
appears.
Automatic
Automatic
Automatic
Automatic
Temperature
A
PPLICATION
