MENU After you log in, the user interface displays a MENU button on the
top of the screen at all times. Selecting the MENU button displays the menu
screen from which you can navigate through the user interface options. See
Using the Menus on page 62
Message The message icon indicates the status of library components, as
described in the following table. Select the icon to view system messages
(see
Refresh Selecting the refresh button forces an update to the information
currently displayed on the user interface. The library controller refreshes
different screens at different rates, depending on the type of data
displayed.
Time Shows the last time that the screen was refreshed. The screen can be
set to refresh at designated intervals (see
you can refresh it as needed by selecting the refresh button.
User Shows the name of the user currently logged in (see
Library Users on page
IP Address or Library Name This information is different between the LC
and the RLC, as shown here:
December 2008
The Menu button also acts as a "back" button in most screens. It
Note:
returns you to the top level menu in the given menu structure.
For example, selecting the Menu button in a Partition screen
returns you to the Configuration screen.
Check Screen Messages on page
Icon Description
.
System OK There are no system messages. If you clear all of the items
in the message screen, the library displays the green checkbox icon.
.
Information An informational message about a system component is
available. Check messages to determine the component.
Attention (warning message)
Check messages to determine the component.
Error or Fatal message. A system component has experienced an error
condition. Check messages to determine the component.
Library Controller—shows the library's IP address.
Remote Library Controller—shows the library's name, if set (see
Library Settings on page
displays in this location.
for a description of the available options.
186).
.
A system component requires attention.
Library Settings on page
73).
81). If the library name is not set, nothing
User Interface Overview
81) or
Configure
Spectra T50e library
