2. Remove one or both magazines, load the cartridges with the bar code
Expansion slots located at back of library—see
Cartridge Capacity Sled on page 113
Left-side magazines
20
Top
16
12
8
4
Bottom
Load the cartridges beginning at slot 1 and continuing sequentially.
Ensure that you reinsert the magazines in the same locations where they were
previously located to prevent corrupting inventory.
Figure 75 Loading cartridges via Bulk Load.
3. Press Continue to load the right side magazines if you purchased the
December 2008
labels facing out, and carefully reinsert the magazine(s) into the library.
23
19
15
HH tape drive
11
10
7
3
6
9
2
5
1
Access port
Bottom left magazine: Access port, Slots 1 through 11
Top left magazine: Slots 12 through 23
Bottom right magazine: Slots 24 through 35
Top right magazine: Slots 36 through 47
Expansion slots: add up to 3 more cartridges here
Note: Be sure and put the magazines back in their original location to
prevent move fails or data corruption.
If this is your initial setup—the first time you are loading
cartridges into the library—the cartridge location is dependent
only on your capacity license and they can go into any of the
magazines, but the magazines still need to go into their original
locations.
Do not insert cartridges in slots outside of your capacity license
locations or they will not be seen by the library or your backup
software. In other words, do not insert cartridges in slots above
12 if you only have a license for 10-slots.
option of using these slots, or Stop Importing to complete the process.
Once you press Stop Importing, the library locks the magazines and
performs inventory.
Add or Remove a
for information about these slots.
50
49
47
48
43
39
35
31
27
Important!
Import and Export Cartridges
Right-side magazines
44
Top
40
36
32
28
Bottom
24
