Access Port

The library includes one slot for importing or exporting a single cartridge
without affecting the library's operation.See
on page
Figure 5 Access Port
December 2008
98.
Access
port
Importing—You can use the Access port door to import media from the
library. When the door opens, the bottom slot in the lower left magazine
slides out of the library far enough to let you insert a cartridge in the
slot. When you close the door, the slot slides back into the magazine
where it can be accessed by the transporter.
Exporting—When exporting media from the library, the transporter
moves the requested cartridge to the slot in the access port. You then
access the user interface to open the door and remove the cartridge.
Library Management
Import and Export Cartridges
Spectra T50e library
23
