Spectra Logic T-Series Spectra T50e User Manual page 238

Appendix C — Specifications
Figure 183
alphanumeric characters above the bar code. All dimensions are in
millimeters (mm).
Bar code start character
16.993
+0/–.787
Quiet Zone
2X 4.318
minimum
Figure 183 Bar code specifications for half-inch media; alphanumeric characters on top.
Figure 184
alphanumeric characters below the bar code. All dimensions are in
millimeters.
Quiet Zone
2X 4.318 mm
minimum
16.993
+0/–.787
Bar code
start character
Figure 184 The bar code specifications for half-inch media; alphanumeric on bottom.
238
User Guide
shows the dimensional specifications for labels with the
Alphanumeric
74.092
78.994
shows the dimensional specifications for labels with the
Note: When using bar code labels with alphanumeric characters along
the bottom edge, the bar code must extend at least 13.72 mm
below the top edge of the cartridge to ensure that the bar code
reader can read the label.
78.994
74.092
Alphanumeric
characters
characters
0.381
•
0.787
•
0.787
•
0.381
•
Edge of cartridge
Bar code label
11.1
minimum
Edge of cartridge
13.72
min.
11.1
Bar code label
90970015
