Chapter 2 — Library Installation
C
ONNECT THE
Follow these steps connect the AC power cords to the library. Only use the
power cord supplied with the library!
1. Plug the AC power cord into the AC connector on the power supply
Figure 22 Connect the AC power cords.
2. Connect the free end of the power cord into the nearest properly
50
User Guide
AC P
OWER
module (Figure 22). Make sure that the cord is fully seated in the
connector.
Power supply 2
slot location
AC power cord
grounded AC power outlet.
Each power supply has three indicator LEDs:
LED Color
Blue
Amber
Green
Note: Refer to the Power Supply Installation or Replacement Instructions
to install a redundant power supply.
Description
AC power is on and functioning normally
Power fault (normally off)
DC power is on and functioning normally
