Chapter 1 — Library Overview
D
RIVES
The library's drives are installed in modular drive bay assemblies (DBAs).
Each DBA has four drive bays and can accommodate up to four full-height
tape drives or four RXT drives. Drives are hot-swappable to provide
uninterrupted operation.
Each drive is mounted in a drive sled which provides the electrical and
logical connections to the library. The drive sled includes intelligence
which assigns a serial number to the drive based on its location in the
library. This location-based serial number remains constant even if the
physical drive is replaced by a new drive. The new drive simply retains the
designated serial number, so drive replacement is completely transparent
to the backup software.
In addition to the electrical connections for the drive, the drive sled
includes a handle to simplify sliding the drive into or out of a drive bay
and a lock to prevent the drive from being accidentally pulled out of the
library.
SCSI terminator
Figure 7 The SCSI drive sled.
Depending on the type of drive, the drive sled includes the following
connectors:
32
User Guide
Handle Lock
release
Ultra-3 SCSI "LVD" 68-pin Micro D female connector (see
Used on SCSI drives with or without a QIP. For QIP-attached drives, a
SCSI terminator (shown in
using direct-attach SCSI tape drives, either a terminator or an LVD SCSI
cable is installed on the connector. See
for information about using direct-attach SCSI tape drives.
Two multi-mode, fixed optical SC connectors (see
connect direct-attach Fibre Channel tape drives to a Fibre Channel
network. See Direct Attach Fibre Channel on page 45
about using direct-attach Fibre Channel tape drives.
Fibre Channel
connectors (2)
Figure 8 The Fibre Channel drive sled.
Figure 7) is installed on the connector. When
Direct-Attach SCSI on page 46
Handle Lock
release
Figure 7) –
Figure 8) – Used to
for information
