Chapter 7 — Using Partitions
9. Select Save.
10. Add as many CHAP entries as necessary, selecting Save after each. If
11. After you finish configuring all of the required CHAP entries, proceed
12. If you selected both E-QIP ports in the Drive Visibility screen

Configuring a Direct-Attach Fibre Channel Partition

When you select one of the direct-attach Fibre Channel drives in a partition
as the controller, you create a direct-attach Fibre Channel partition (see
Choose the Robotic Control Path on page
each drive in the partition connects directly to the Fibre Channel network.
156
User Guide
Do not select Next before selecting Save, or you will lose all of the
Note:
configuration settings you just completed.
After selecting Save, the first CHAP entry displays at the top of the screen.
necessary, you may also edit entries from the Exporting CHAP Settings
screen.
to Step 12.
on page 151), return to
configuration steps in this section for the other E-QIP port.
If you only selected one E-QIP port in the Drive Visibility screen or if
you have already configured both E-QIP ports, proceed to
Save Partition Settings on page
Configure the E-QIP on page 152
162.
142). In this type of partition,
(Figure 85
and repeat the
Confirm and
91090000
