H E
ARDWARE XPANSION AND
The Spectra T200, T380, and T680 libraries are designed to expand to meet
a data center's changing storage requirements, as well as to achieve storage
consolidation goals. These expansion and upgrade options can be
purchased through a sales representative (see
page
Logic online store at www.spectralogic.com/shop.
The following table describes the types of hardware expansion and
upgrades that are available.
Hardware
Drives
Quad Interface
Processors (QIPs)
and Bus Expansion
Modules
Power Supplies
BlueScale Vision
camera
USB key
R
EPLACEABLE
Some library components are extremely easy to remove and install. They
are classified as customer-replaceable units (CRUs) and they are available
for purchase based on your service contract with SpectraGuard Technical
Support (see
336
User Guide
5). Selected options are also available for purchase from the Spectra
Description
Each library drive bay assembly (DBAs) holds up to four drives. If a DBA is not
full, additional drives can be installed to increase data throughput. Similarly, if
fewer than three QIPs are installed, additional QIPs can be easily installed to
increase the library's throughput. Both drives and QIPs are sled-mounted and
install in under two minutes.
The type of QIP installed in the library can be changed at any time to match the
network to which the library is connected. Bus expansion modules are required
when using direct-attach SCSI drives in the library.
The library requires one power supply per DBA. Adding another power supply
per DBA provides 2N redundancy and failover protection. The power supply
modules needed for the 2N power redundancy configuration are an option you
can purchase separately or when you order the library.
The web-based BlueScale Vision camera lets you visually monitor the
interior of the library. The BlueScale Vision camera is an option you can
purchase when you order your library.
You can use USB key when upgrading the library's firmware package or as a
troubleshooting tool for use as instructed by Technical Support. USB key are
available for purchase from Spectra Logic for a nominal charge.
C
OMPONENTS
Appendix C – Service and
Drives
QIPs
Library Control Module (LCM)
Power supply modules
U
PGRADES
Support). CRUs include:
Contacting Spectra Logic on
