Troubleshooting Lto Tape Drives - Spectra Logic T-Series Spectra T200 User Manual

T
ROUBLESHOOTING
LTO drives have an LED and a single-character display (SCD) which
provide information about the drive's operational status. These LEDs are
not visible when the drive is operating inside the library. Instead, the LED
state and SCD code information for each LTO drive in a partition can be
viewed using the Drive Details screen
If you think that a drive may be faulty, follow these steps:
1. Display the Drive Details screen for the drive you suspect is having
2. Refer to the following table to interpret the information on the Drive
3. If the drive is in an error state, contact SpectraGuard Technical Support
Detail Field
POST Status
Cleaning Status
LED Status
Display Character
Cartridge Status
December 2008
If the SCSI bus is not properly terminated you may experience one or
more of the following failure symptoms:
Read/Write failure.
Bus hangs.
Connectivity issues—drive is not seen on bus or drops off bus.
Command failures—commands to a drive may fail while
commands to other devices on the bus may work properly.
LTO T
APE
problems (see Viewing Drive Status Information on page
Details screen.
(see Contacting Spectra Logic on page
Description
Indicates whether the drive successfully completed its power-on self-tests
(POST).
When an LTO drive power-cycled or reset, it automatically runs self-diagnostic
tests (POST), checking memory and sensors, performing motor and servo tests,
and testing data channels to ensure that the drive is functioning within normal
parameters.
Indicates whether the drive requires cleaning (see
page 306).
Corresponds to the status LED on the drive.
See Interpreting the LTO Status LED on page 276
Corresponds to the single-character display (SCD) on the drive.
The meaning of the character displayed depends on whether the drive is LTO-4,
LTO-3, or LTO-2. See Interpreting the Display
for detailed information.
Indicates whether a cartridge is currently loaded in the drive, tape motion, and
other information related to reading and writing data.
D
RIVES
(Figure 186 on page
5).
for detailed information.
Character, beginning on
T200, T380, and T680 Libraries

Troubleshooting LTO Tape Drives

274).
273).
Cleaning a Tape Drive on
page 277
275
