Appendix D — Specifications
100–130 VAC Power Cord for Use
included with library are standard, three conductor, 14-gauge AC power
cords safe for 100-volt to 130-volt use in the United States and Canada. The
cable has a molded NEMA 5-15P male connector to plug into the wall and
an IEC 60320-C19 female connector to plug into the library. The male
connector does not have a twist lock. An additional grounding wire from
the chassis to earth ground is required.
Risk of electrical shock. To prevent the possibility of electrical shock, install cord
Warning
locks on the AC power cords and a permanent grounding wire between the chassis
and earth ground.
German: Gefahr eines elektrischen Schlages. Um zu verhindern, dass die
Möglichkeit eines elektrischen Schlages, der Installation von Kabel-Sperren auf
den AC Netzkabel und eine ständige Erdung Draht zwischen den Chassis und
Masse.
Refer to the table in
Caution
maximum number of drives that can be installed when operating the library at 100–
130 VAC.
200–240 VAC Power Cord for Use in North America and Korea The criteria
for a 200-volt to 240-volt AC power cord in North America and Korea are
as follows:
200–240 VAC Power Cord for International Use The criteria for an
international 200-volt to 240-volt AC power cord are as follows:
350
User Guide
Input Power Requirements on page 349
Note: To use the library outside of North America, the power cord
must meet the specifications for that country, as described in the
following sections. If the male connector does not have a twist
lock, an additional grounding wire from the chassis to earth
ground is required.
Power cord must have a molded NEMA L6-20P male connector on one
end.
Power cord must have a molded IEC 60320-C19 female connector to
plug into the library.
Cordage must be SJT type, three-conductor, 16 AWG minimum.
Power cord must comply with local electrical code.
Power cord must have an attachment plug of the proper type, rating,
and safety approval for the intended country.
Cord must be a flexible, HAR (harmonized) type H05VV-F, three
conductor, cord with minimum conductor size of 0.03 square inches
(1.0 square millimeter).
Power cord must have a molded IEC 60320-C19 female connector on
one end to plug into the library.
in North America
The power cables
to determine the
