Figure 3 The BlueScale Vision camera and LEDs
December 2008
Media chambers. Each horizontal shelf inside the library is divided
into three semi-enclosed chambers. Each chamber provides storage for
one TeraPack magazine or one RXT media pack. Storing the media
horizontally dramatically increases storage density.
In addition to the chambers indicated in
installed in the flex bays at the back of the library (see
Components on page
stored in the library depends on the type of media and the number of
drives installed (see Data Storage Capacity on page
Transporter. The robotic transporter performs all media movement
within the library. The integrated bar code reader mounted on the
transporter reads the bar code labels on individual TeraPack
magazines, cartridges, and RXT media packs. The library uses the bar
code label information to maintain an inventory of the media currently
stored inside the library. To learn more about the transporter, see
Transporter on page 34.
BlueScale Vision camera. The optional BlueScale Vision camera and
LED lights let you view the interior of the library while it is operating
using a web-based Network Camera viewer. The viewer connects to the
camera using the dedicated Ethernet connection on the library back
panel (see Figure 4 on page
Note: The BlueScale Vision camera is not available as a retrofit for
early models of the T200 and T380 libraries.
LED lighting. Two LEDs illuminate the interior of the library.
Figure
28). The maximum amount of media that can be
28).
LEDs (one on each
side of camera)
T200, T380, and T680 Libraries
Library Components
2, chambers can also be
Rear Panel
346).
Camera lens
Ethernet and
power cables
