Chapter 11 — Library Troubleshooting

Before You Begin

Access the Interior from the Front

If you cannot access the sides of the library while it is installed the rack, use
the steps in the following sections to remove the front panel, fan assembly,
and chamber shelves.
Remove the Front Panel
1. From the front of the library, pull firmly outward on the top edge of the
2. Lift the cover upward to disengage the tabs on each side of the cover
3. Remove the cover and set it aside.
260
User Guide
Capture all available traces (see
data generated by the library or other components may be lost when
you perform a reset, making diagnosing problems difficult.
Power down the library (see
Note: Do not remove the library from the rack.
filter cover panel to release the magnetic latches and tip the cover out
from the front pane.
Pull outward
Figure 170 Removing the filter
cover panel.
from the slots in the front of the library.
Capturing Traces on page
Power Off the Library on page
Tab
Lift upward
250). Trace
78).
