4. Using your fingers or a #2 Phillips screwdriver, loosen, but do not
Figure 171 Removing the front panel screws.
5. Lift the front panel outward and away from the chassis to disengage the
Figure 172 Removing the front panel.
December 2008
remove, the two knurled screws securing the bottom of the library front
panel to the chassis.
two nuts on the back of the front panel from the holes on either side of
the chassis. Set the cover aside.
Access the Library Interior to Check for Blockages
T200, T380, and T680 Libraries
Knurled
screws
Chassis
Alignment nut on
front panel
261
