Chapter 11 — Library Troubleshooting
Resetting the LCM
To reset the LCM, insert the tip of a toothpick or other similar non-
conductive object into the hole on the back of the LCM to press the reset
button.
Do not use a metallic object to reset the LCM. You may inadvertently cause an
Caution
electrical short inside the module.
Resetting the LCM also resets the motion control for the transporter. Any move
Important
requests to the transporter will fail until the LCM completes its initialization.
Figure 165 Resetting the LCM.
Resetting a QIP
To reset a QIP, insert the tip of a toothpick or other similar object into the
hole in the QIP back panel to press the reset button.
Do not use a metallic object to reset a QIP. You may inadvertently cause an
Caution
electrical short inside the module.
252
User Guide
LMC reset
Note:
QIPs are mounted vertically along the right side of each DBA.
The QIP in
Figure 166
reference only.
Figure 166 Resetting a QIP (F-QIP shown).
is shown in a horizontal position for
QIP Reset
91090000
