Appendix D — Specifications
366
User Guide
Bar codes should be eight characters plus a checksum.
The bar code string is printed on the label so it is on the side toward the
hub.
Label stock must fit within the label recess on the face of the cartridge
without curling up on the sides or ends (79 mm X 17 mm +0 or –0.8).
Label stock dimensions:
Minimum length sufficient for the quiet zones, start-stop, and data
characters (nominal 74.088 mm).
Minimum width no less than 1.5 mm narrower than the cartridge
label recess width. Corners are cut with a 1.5 mm radius.
The bar codes must be standard half-inch media format:
A total of eight (8) horizontal alphanumeric characters are used for
volume and media identification.
There must be a checksum included in the barcode.
The minimum leading quiet zone should be 4.318 mm and the
maximum leading quiet zone should be 4.318 mm.
Volume identifiers:
Must be limited to the use of ASCII characters A – Z (41h – 5Ah),
0 – 9 (30h – 39h).
The field consists of six (6) left-justified alphanumeric characters.
The media identifier characters Gg are controlled characters. The G
designates the type of data cartridge. The g indicates the generation
and capacity of the cartridge.
