Chapter 1 — Library Overview
In addition to the components shown in
additional components are present on the rear panel during normal
operation.
L T
IBRARY OUCH
The 8.4-inch color touch screen on the front of the library provides access to
the BlueScale user interface through the Library Controller (LC). You can
select options and enter information by simply touching the appropriate
location on the screen. A stylus included with the library simplifies using
the touch screen. The user interface displayed on the library's touch screen
includes a soft keyboard you can use to enter alphanumeric characters into
text fields. This soft keyboard can be accessed from the keyboard icon that
displays whenever text input is required.
The user interface lets you set configuration options, view library and
drive information and metrics, manage media, monitor library operations,
and perform maintenance operations. For detailed information about the
BlueScale user interface, see
30
User Guide
A DBA cover (shown in
in the T200 and T380 libraries.
Doors on the T680 rack enclose the back of the library.
Cord locks are installed to prevent the AC power cords from being
disconnected (see Figure 14 on page
A permanent grounding wire is connected to the chassis (see
on page 38).
Any bays that do not contain components have covers installed to
maintain proper air circulation through the library.
S
CREEN AND
Figure 5 The General Status screen of the user interface through
the library controller (T380 shown).
Figure 4 on page
Figure 2 on page 26) is installed over the drives
38).
U I
SER NTERFACE
Understanding the User Interface on page
28, the following
Figure 14
66.
