M
EDIA
Spectra's TeraPack media architecture provides support for both
traditional tape media and RXT media.

TeraPack Media

The libraries use TeraPack magazines to import and export cartridges
through the TAP and to store cartridges inside the library. Each magazine
holds up to 10 LTO or SAIT cartridges, or 9 SDLT cartridges.The magazine
has guides along each side to ensure proper alignment when it is inserted
in the TAP.
December 2008
The AC connector and switch on the right side of the chassis control
power to the three power supply modules to the immediate left of
the connector. If you are not using 2N redundant power supplies,
these modules are typically installed first.
The AC connector and switch on the left side of the chassis control
power to the power supply modules installed to the immediate
right of the connector.
Cord locks on each power cord secure the cord to the library to
prevent it from being inadvertently disconnected.
A permanent ground wire is connected to the power supply bay to
ensure that the library is properly grounded at all times.
Each power supply module has two indicator LEDs (shown in
Figure 14), one for AC power status and one for DC power status.
Green – The power is on and functioning normally.
Off – The power is not on or the power supply module is not
functioning normally.
Cartridge bar
code label
TeraPack bar
code label
Alignment guides
Figure 15 TeraPack magazine with bar code labeled cartridges.
T200, T380, and T680 Libraries

Media
