4. Slide the clamp over the AC power cord and reinstall the screws and
5. Tighten the screws to secure the mounting bracket to the chassis and
6. If you are using redundant power supply modules, repeat Steps 1
7. Plug the supply end of each power cord into a separate AC branch
December 2008
kep nuts to secure the clamp to the cord.
Figure 199 Assembled cord
lock with power cord (removed
from AC switch plate for clarity).
lock the power cord in place.
Screws
Figure 200 Secure the cord lock assembly to the chassis.
through 5 to install a cord lock on the second AC power cord.
circuit.
Note: If the AC supply outlet does not have a locking connector, make
sure you connect a permanent grounding wire to the power
supply bay (see Install a Grounding Wire).
T200, T380, and T680 Libraries
Installing Chassis Grounding
