Exception Number IRQx
32 IRQ16
33 IRQ17
34 IRQ18
35 IRQ19
36 IRQ20
37 IRQ21
38 IRQ22
39 IRQ23
40 IRQ24
41 IRQ25
42 IRQ26
43 IRQ27
44 IRQ28
45 IRQ29
46 IRQ30
47 IRQ31
48 IRQ32
49 IRQ33
50 IRQ34
51 IRQ35
52 IRQ36
53 IRQ37
54 IRQ38
55 IRQ39
56 IRQ40
57 IRQ41
58 IRQ42
59 IRQ43
60 IRQ44
61 to 63 IRQ45
to
IRQ47
64 IRQ48
65 to 67 IRQ49
to
IRQ51
68 IRQ52
69 IRQ53
70 IRQ54
71 IRQ55
72 IRQ56
73 IRQ57
74 IRQ58
75 IRQ59
76 IRQ60
77 IRQ61
78 IRQ62
79 IRQ63
1
The corresponding PCLK is required to generate the interrupt.
Vector
SPI1
2
I C slave
2
I C master
DMA Error
DMA Channel 0 done
DMA Channel 1 done
DMA Channel 2 done
DMA Channel 3 done
DMA Channel 4 done
DMA Channel 5 done
DMA Channel 6 done
DMA Channel 7 done
DMA Channel 8 done
DMA Channel 9 done
DMA Channel 10 done
DMA Channel 11 done
DMA Channel 12 done
DMA Channel 13 done
DMA Channel 14 done
DMA Channel 15 done
Reserved
Reserved
Reserved
Reserved
Digital Die General-Purpose Timer 2
Digital die crystal oscillator
Reserved
Reserved
Reserved
Reserved
Analog die ADC
Reserved
Analog die watchdog timer
Reserved
Analog Die General-Purpose Timer 0
Analog Die General-Purpose Timer 1
Reserved
DMA analog die data FIFO (DMA Channel 17)
DMA Channel 18 done
DMA Channel 19 done
DMA Channel 20 done
DMA Channel 21 done
DMA Channel 22 done
DMA Channel 23 done
