REGISTER SUMMARY: ANALOG DIE GENERAL-PURPOSE TIMERS

Table 351. AGPT0 Register Summary
Address Name
0x400C0D00 LD0
0x400C0D04 VAL0
0x400C0D08 CON0
0x400C0D0C CLRI0
0x400C0D14 ALD0
0x400C0D18 AVAL0
0x400C0D1C STA0
0x400C0D20 PWMCON0
0x400C0D24 PWMMAT0
0x400C0D28 INTEN
Table 352. AGPT1 Register Summary
Address Name
0x400C0E00 LOAD
0x400C0E04 CURCNT
0x400C0E08 CTL
0x400C0E0C CLRINT
0x400C0E14 ALOAD
0x400C0E18 ACURCNT
0x400C0E1C STAT
0x400C0E20 PWMCTL
0x400C0E24 PWMMATCH
Description
16-bit load value
16-bit timer value
Control
clear interrupt
16-bit load value, asynchronous
16-bit timer value, asynchronous
Status
PWM control
PWM match value
Interrupt enable
Description
16-bit load value
16-bit timer value
Control
Clear interrupt
16-bit load value, asynchronous
16-bit timer value, asynchronous
Status
PWM control
PWM match value
Rev. B | Page 275 of 312
UG-1262
Reset Access
0x0000 R/W
0x0000 R
0x000A R/W
0x0000 W
0x0000 R/W
0x0000 R
0x0000 R
0x0000 R/W
0x0000 R/W
0x0000 R/W
Reset Access
0x0000 R/W
0x0000 R
0x000A R/W
0x0000 W
0x0000 R/W
0x0000 R
0x0000 R
0x0000 R/W
0x0000 R/W
