Analog Devices ADuCM355 Hardware Reference Manual page 138

UG-1262
Sequence 3 Information Register
Address: 0x400C21E4, Reset: 0x00000000, Name: SEQ3INFO
Table 169. Bit Descriptions for SEQ3INFO Register
Bits Bit Name
[31:27] Reserved
[26:16] INSTNUM
[15:11] Reserved
[10:0] STARTADDR
Sequence 1 Information Register
Address: 0x400C21E8, Reset: 0x00000000, Name: SEQ1INFO
Table 170. Bit Descriptions for SEQ1INFO Register
Bits Bit Name
[31:27] Reserved
[26:16] SEQ1INSTNUM
[15:11] Reserved
[10:0] SEQ1STARTADDR
Command and Data FIFO Internal Data Count Register
Address: 0x400C2200, Reset: 0x00000000, Name: FIFOCNTSTA
Table 171. Bit Descriptions for FIFOCNTSTA Register
Bits Bit Name
[31:27] Reserved
[26:16] DATAFIFOCNTSTA[10:0]
[15:0] Reserved
Trigger Sequence Register
Address: 0x400C0430, Reset: 0x0000, Name: TRIGSEQ
Table 172. Bit Descriptions for TRIGSEQ Register
Bits Bit Name
[15:4] Reserved
3 TRIG3
2 TRIG2
1 TRIG1
0 TRIG0
ADuCM355
Description
Reserved.
SEQ3 Instruction Number.
Reserved.
SEQ3 Start Address.
Description
Reserved.
SEQ1 Instruction Number.
Reserved.
SEQ1 Start Address.
Description
Reserved.
Current Number of Words in the Data FIFO.
Reserved.
Description
Reserved.
Trigger Sequence 3.
Trigger Sequence 2.
Trigger Sequence 1.
Trigger Sequence 0.
Rev. B | Page 138 of 312
Hardware Reference Manual
Reset
0x0
0x0
0x0
0x0
Reset
0x0
0x0
0x0
0x0
Reset
0x0
0x0
0x0
Reset Access
0x0 R
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/WS
Access
R
R/W
R
R/W
Access
R
R/W
R
R/W
Access
R
R
R
