POWER MODE REGISTER
Address: 0x4004C008, Reset: 0x00000000, Name: PWRMOD
Table 25. Bit Descriptions for PWRMOD
Bits
Bit Name
Settings
[31:4]
Reserved
3
MONVBATN
2
Reserved
[1:0]
MODE
KEY PROTECTION FOR PWRMOD AND SRAMRET REGISTER
Address0x4004C00C, Reset: 0x00000000, Name: PWRKEY
Table 26. Bit Descriptions for PWRKEY
Bits
Bit Name
Settings
[31:16]
Reserved
[15:0]
VALUE
Description
AVDD_DD Range 1 (>2.75 V). This is a write one to clear status bit indicating the
relevant AVDD_DD range. Generates the AVDD_DD range interrupt if IEN, Bit 10
is set. The status bit sets again even after 1 is written to the flag to clear it if
AVDD_DD falls in the specified range.
1
AVDD_DD in the specified range.
0
AVDD_DD not in the specified range.
Wake-Up Interrupt Controller (WIC) Enable Acknowledge from Cortex.
Reserved.
Status Bit for Alarm Indicating Overvoltage for DVDD_REG. Bit set if DVDD_REG
(LDO regulator output) > 1.32 V. Generates an interrupt if IEN, Bit 2 is set. This is
write one to clear this bit. The status bit sets again even after 1 is written to the
flag to clear it if DVDD_REG is > 1.32 V.
Status Bit for Alarm Indicating DVDD_REG is Less Than 1 V. Generates an interrupt if
IEN Bit 1 is set. This bit sets if DVDD_REG < 1 V. This is a write one to clear bit. The
status bit sets again even after 1 is written to the flag to clear it if DVDD_REG is < 1 V.
Status Bit Indicating an Alarm that AVDD_DD is Less than 1.8 V. Generates an
interrupt if IEN Bit 0 is set. This bit sets if AVDD_DD < 1.83 V. This is a write one
to clear bit. The status bit sets again even after 1 is written to the flag to clear it if
AVDD_DD is < 1.83 V.
Description
Reserved.
Monitor AVDD_DD During Hibernate Mode. Monitors AVDD_DD by default.
DVDD_REG (1.2 V LDO regulator). Monitoring cannot be disabled.
0
AVDD_DD monitor enabled in PMU block. Default.
1
AVDD_DD monitor disabled in PMU block.
Reserved.
Power Mode Bits.
00
Flexi mode.
01
Reserved.
10
Hibernate mode.
11
Reserved
Description
Reserved.
Power Control Key Register. The PMG0 PWRMOD and PMG0 SRAMRET registers are
key protected. One write to the key is necessary to change the value in the PMG0
PWRMOD and PMG0 SRAMRET registers. Write 0x4859 to PMG0 PWRKEY before
writing to PMG0 PWRMOD or PMG0 SRAMRET register. A write to any other
register on the Arm peripheral bus before writing to PMG0 PWRMOD or PMG0
SRAMRET returns the protection to the lock state.
Rev. B | Page 31 of 312
UG-1262
Reset
Access
0x1
R/W1C
0x0
R
0x0
R
0x0
R/W1C
0x0
R/W1C
0x0
R/W1C
Reset
Access
0x0
R
0x0
R/W
0x0
R/W
0x0
R/W
Reset
Access
0x0
R
0x0000
W
