AFE INTERRUPTS

There are interrupt options available on the ADUCM355 analog front end that can be configured to toggle the internal GPIO pin on the digital
die. The GPIO pin is connected internally and is not bonded out of the LGA package.

INTERRUPT CONTROLLER INTERUPTS

The interrupt controller is divided into two blocks. Each block consists of an INTCSELx register and an INTCFLAGx register. Only
INTCSEL0 interrupts are connected to the digital die by the internal GPIO pin. The INTCSEL1 interrupts are only used for polling. The
INTCPOL and INTCCLR registers are common to both blocks. When an interrupt is enabled in the INTCSELx register, the
corresponding bit in the INTCFLAGx register is set. The available interrupt sources are shown in Table 173.

CONFIGURING THE INTERRUPTS

The first step to configure the INTC interrupts is to configure the digital die GPIO pin that connects internally to the AFE interrupt
controller output. To configure the GPIO pin, take the following steps:
1. Configure the internal GPIO2 Pin 1 as a GPIO as follows:
DioCfgPin(pADI_GPIO2, PIN1, 0);
2. Configure the internal P2.1 pin as an input as follows:
DioIenPin(pADI_GPIO2, PIN1, 1); /* Enable P2.1 input path. */
3. Enable External Interrupt 3 and configure for falling edge as follows:
EiCfg(EXTINT3, INT_EN, INT_FALL); /* Falling edge. */
4. Enable the interrupt in the NVIC as follows:
NVIC_EnableIRQ(AFE_EVT3_IRQn);
When these steps are complete, the digital die is configured for INTC interrupts. To configure the AFE INTC interrupts, first write to the
INCT0POL to configure the polarity. To enable the required interrupt, write to the INTCSEL0 register. To clear an interrupt source,
write to the corresponding bit in the INTCCLR register.

CUSTOM INTERRUPTS

Four custom interrupt sources are selectable by the user in the INTCSELx register, Bits[12:9]. For these custom interrupts to generate an
interrupt event, write to the corresponding bit in the AFEGENINTSTA register. It is only possible to write to this register via the sequencer.
Table 173. Interrupt Sources Summary
INTCFLAGx Register Flag Name
FLAG0
FLAG1
FLAG2
FLAG3
FLAG4
FLAG5
FLAG6
FLAG7
FLAG13
FLAG15
FLAG16
FLAG17
FLAG23
FLAG24
FLAG25
FLAG26
FLAG27
FLAG29
FLAG31
Interrupt Source Description
ADC result IRQ status.
DFT result IRQ status.
Sinc2 filter result ready IRQ status.
Temperature result IRQ status.
ADC minimum fail IRQ status.
ADC maximum fail IRQ status.
ADC delta fail IRQ status.
Mean IRQ status.
Bootload done IRQ status.
End of sequence IRQ status.
Sequencer timeout finished IRQ status (see the Timer Command section).
Sequencer timeout command error IRQ status (see the Timer Command section).
Data FIFO full IRQ status.
Data FIFO empty IRQ status.
Data FIFO threshold IRQ status, threshold value set in DATAFIFOTHRES register.
Data FIFO overflow IRQ status.
Data FIFO underflow IRQ status.
Outlier IRQ status, detects when an outlier is detected.
Attempt to break IRQ status. This interrupt is set if a Sequence B request occurs when Sequence A is
running. This interrupt indicates that Sequence B is ignored.
