ADuCM355 Hardware Reference Manual
Bits Bit Name Settings
1 IRQ
0 PDSTOP

REFRESH WATCHDOG REGISTER

Address: 0x400C090C, Reset: 0x0000, Name: WDTCLRI
Table 376. Bit Descriptions for WDTCLRI
Bits Bit Name Settings
[15:0] CLRWDG

TIMER STATUS REGISTER

Address: 0x400C0918, Reset: 0x0000, Name: WDTSTA
Table 377. Bit Descriptions for WDTSTA
Bits Bit Name Settings
[15:7] Reserved
6 TMINLD
5 Reserved
4 LOCK
3 CON
2 TLD
1 CLRI
0 IRQ
Description
WDT Interrupt Enable.
0 Watchdog timer timeout creates a reset.
1 Watchdog timer timeout creates an interrupt instead of a reset.
Power Down Stop Enable.
0 Continue counting when in hibernate mode. The watchdog timer continues its
count down while in hibernate mode.
1 Stop counter when in hibernate mode. When hibernate mode is entered, the
watchdog counter suspends its countdown. As hibernate mode is exited, the
countdown resumes from its current count value (the count is not reset).
Description
Refresh Register. User writes 0xCCCC to reset, reload, or restart the counter or clear the
IRQ. A write of any other value causes a watchdog reset or IRQ. Write only, reads 0.
Description
Reserved.
WDTMINLD Register Write Status.
0 The WDTMINLD value is fully updated. Arm and AFE watchdog clock domains and the
WDTMINLD values match.
1 WDTMINLD value update in progress. Arm peripheral bus and the WDTMINLD value are
being synchronized to the 32 kHz clock domain.
Reserved.
Lock Status.
0 Timer operation not locked.
1 Timer enabled and locked. Set automatically in hardware when WDTCON, Bit 5 has
been set by user code.
WDTCON Write Status.
0 WDTCON is up to date. Arm peripheral bus and watchdog timer clock domains match
WDTCON values.
1 WDTCON register synchronizing. The Arm peripheral bus and watchdog timer clock
domains are in the process of synchronizing with the WDTCON values.
WDTVALS Write Status.
0 Arm and AFE watchdog clock WDTLD register values match.
Synchronize in progress. Arm peripheral bus WDTLD value is being synchronized to the
1
32 kHz clock domain.
WDTCLRI Write Status.
0 Arm peripheral bus WDTCLRI write synchronization not complete.
1 Arm peripheral bus WDTCLRI write is being synchronized to WDT clock domain. WDT
restarts (if 0xCCCC was written) when latter synchronization is complete.
WDT Interrupt. Set to 1 when watchdog timer interrupt occurs.
0 Watchdog timer interrupt not pending.
1 Watchdog timer interrupt pending. Cleared by writing to WDTCLRI register.
Rev. B | Page 285 of 312
UG-1262
Reset Access
0x0 R/W
0x1 R/W
Reset Access
0x0 W
Reset Access
0x0 R/W
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
