REGISTER SUMMARY: POWER MANAGEMENT UNIT

Table 21. Digital Die Power Management Register Summary (PMG0 Stack)
Address Name
0x4004C000 IEN
0x4004C004 PSM_STAT
0x4004C008 PWRMOD
0x4004C00C PWRKEY
0x4004C014 SRAMRET
0x4004C044 CTL1
0x4004C260 SRAM_CTL
0x4004C264 SRAM_INITSTAT
Table 22. Analog Die Power Management Register Summary (ALLON Stack)
Address Name
0x400C0A00 PWRMOD
0x400C0A04 PWRKEY
Description
Power supply monitor interrupt enable
Power supply monitor status
Power mode
Key protection for PWRMOD and SRAMRET
Control for retention SRAM during hibernate mode
High power buck control
Control for SRAM parity and instruction SRAM
Initialization status
Description
Power modes
Key protection for PWRMOD
Rev. B | Page 29 of 312
UG-1262
Reset Access
0x00000000 R/W
0x2100 W1C
0x00000000 R/W
0x00000000 W
0x00000000 R/W
0x00000000 R/W
0x80000000 R/W
0x00000001 R/W
Reset Access
0x0001 R/W
0x0000 R/W
