ADuCM355
Hardware Reference Manual
Table 258. AFE Die GPIO Register Summary
Address
Name
0x400C0080
CON
0x400C0084
OEN
0x400C0088
PE
0x400C008C
IEN
0x400C0090
IN
0x400C0094
OUT
0x400C0098
SET
0x400C009C
CLR
0x400C00A0
TGL
Description
AFE GPIO port configuration
AFE GPIO port output enable
AFE GPIO port output pull-up and pull-down enable
AFE GPIO port input path enable
AFE GPIO port registered data input
AFE GPIO port data output
AFE GPIO port data output set
AFE GPIO port data output clear
AFE GPIO port pin toggle
Rev. B | Page 219 of 312
UG-1262
Reset
Access
0x00
R/W
0x0
R/W
0x2
R/W
0x0
R/W
0x0
R
0x0
R/W
0x0
W
0x0
W
0x0
W
