GAIN CALIBRATION VOLTAGE INPUT CHANNEL (PGA GAIN = 1) REGISTER

Address: 0x400C2240, Reset: 0x00004000, Name: ADCGAINGN1
Table 85. Bit Descriptions for ADCGAINGN1
Bits
Bit Name
Settings
[31:15]
Reserved
[14:0]
VALUE
0x7FFF
0x4001
0x4000
0x3FFF
0x2000
0x0001
0x0000

OFFSET CALIBRATION VOLTAGE CHANNEL (PGA GAIN = 1.5) REGISTER

Address: 0x400C22CC, Reset: 0x00000000, Name: ADCOFFSETGN1P5
Table 86. Bit Descriptions for ADCOFFSETGN1P5
Bits
Bit Name
Settings
[31:15]
Reserved
[14:0]
VALUE

GAIN CALIBRATION VOLTAGE INPUT CHANNEL (PGA GAIN = 1.5) REGISTER

Address: 0x400C2270, Reset: 0x00004000, Name: ADCGAINGN1P5
Table 87. Bit Descriptions for ADCGAINGN1P5
Bits
Bit Name
Settings
[31:15]
Reserved
[14:0]
VALUE
0x7FFF
0x4001
0x4000
0x3FFF
0x2000
0x0001
0x0000
Description
Reserved.
Gain Calibration PGA Gain 1. ADC gain correction for voltage input channels.
Stored as a signed number. Bit 14 is the sign bit and Bits[13:0] represent the
fractional part.
2 (maximum positive gain adjustment).
1.000061 (minimum positive gain adjustment).
1.0. ADC result multiplied by 1. No gain adjustment. Default value.
0.999939 (minimum negative gain adjustment).
0.5. ADC result multiplied by 0.5.
0.000061 (maximum negative gain adjustment).
0. Invalid value. Results in ADC result of 0.
Description
Reserved.
Offset Calibration Gain 1.5. ADC offset correction with PGA gain = 1.5.
0x3FFF
4095.75 (maximum positive offset calibration value).
0x0001
0.25 (minimum positive offset calibration value).
0x0000
0 (no offset adjustment).
0x7FFF
−0.25 (minimum negative offset calibration value).
0x4000
−4096 (maximum negative offset calibration value).
Description
Reserved.
Gain Calibration PGA Gain 1.5. ADC gain correction for voltage input channels.
Stored as a signed number. Bit 14 is the sign bit and Bits[13:0] represent the
fractional part.
2 (maximum positive gain adjustment).
1.000061 (minimum positive gain adjustment).
1.0. ADC result multiplied by 1. No gain adjustment. Default value.
0.999939 (minimum negative gain adjustment).
0.5. ADC result multiplied by 0.5.
0.000061 (maximum negative gain adjustment).
0. Invalid value. Results in ADC result of 0.
Rev. B | Page 79 of 312
UG-1262
Reset
Access
0x0
R
0x4000
R/W
Reset
Access
0x0
R
0x0
R/W
Reset
Access
0x0
R
0x4000
R/W
