OFFSET CALIBRATION TEMPERATURE SENSOR CHANNEL 0 REGISTER

Address: 0x400C223C, Reset: 0x00000000, Name: ADCOFFSETTEMPSENS0
Table 94. Bit Descriptions for ADCOFFSETTEMPSENS0
Bits Bit Name Settings
[31:15] Reserved
[14:0] VALUE
0x3FFF
0x0001
0x0000
0x7FFF
0x4000

GAIN CALIBRATION TEMPERATURE SENSOR CHANNEL 0 REGISTER

Address: 0x400C2238, Reset: 0x00004000, Name: ADCGAINTEMPSENS0
Table 95. Bit Descriptions for ADCGAINTEMPSENS0
Bits Bit Name
[31:15] Reserved
[14:0] VALUE

MINIMUM VALUE CHECK REGISTER

Address: 0x400C20A8, Reset: 0x00000000, Name: ADCMIN
Table 96. Bit Descriptions for ADCMIN
Bits Bit Name Settings
[31:16] Reserved
[15:0] MINVAL

MINIMUM SLOW MOVING VALUE REGISTER

Address: 0x400C20AC, Reset: 0x00000000, Name: ADCMINSM
Table 97. Bit Descriptions for ADCMINSM
Bits Bit Name Settings
[31:16] Reserved
[15:0] MINCLRVAL
Description
Reserved.
Offset Calibration Temperature Sensor. ADC offset correction for temperature sensor
channel, represented as a twos complement number. The calibration resolution is
0.25 LSBs of the ADCDAT LSB size.
4095.75 (maximum positive offset calibration value).
0.25 (minimum positive offset calibration value).
0 (no offset adjustment).
−0.25 (minimum negative offset calibration value).
−4096 (maximum negative offset calibration value).
Settings Description
Reserved.
Gain Calibration Temperature Sensor Channel. ADC gain correction for
temperature sensor channel. Stored as a signed number. Bit 14 is the sign bit
and Bits[13:0] represent the fractional part.
0x7FFF 2 (maximum positive gain adjustment).
0x4001 1.000061 (minimum positive gain adjustment).
0x4000 1.0. ADC result multiplied by 1. No gain adjustment. Default value.
0x3FFF 0.999939 (minimum negative gain adjustment).
0x2000 0.5. ADC result multiplied by 0.5.
0x0001 0.000061 (maximum negative gain adjustment).
0x0000 0. Invalid value. Results in ADC result of 0x8000.
Description
Reserved.
ADC Minimum Value Threshold. This value is a low ADCDAT threshold value. If a value
less than ADCMIN is measured by the ADC, the ADCINTSTA, Bit 4 is set to 1.
Description
Reserved.
ADCMIN Hysteresis Value. If a value less than ADCMIN is measured by the ADC,
ADCINTSTA, Bit 4 is set. ADCINTSTA, Bit 4 is set until ADCDAT > ADCMIN +
ADCMINSM, Bits[15:0].
