REGISTER SUMMARY: DIGITAL INPUTS AND OUTPUTS

Table 257. Digital Die GPIO Register Summary
Address Name
0x40020000 GP0CON
0x40020004 GP0OEN
0x40020008 GP0PE
0x4002000C GP0IEN
0x40020010 GP0IN
0x40020014 GP0OUT
0x40020018 GP0SET
0x4002001C GP0CLR
0x40020020 GP0TGL
0x40020024 GP0POL
0x40020028 GP0IENA
0x4002002C GP0IENB
0x40020030 GP0INT
0x40020034 GP0DS
0x40020040 GP1CON
0x40020044 GP1OEN
0x40020048 GP1PE
0x4002004C GP1IEN
0x40020050 GP1IN
0x40020054 GP1OUT
0x40020058 GP1SET
0x4002005C GP1CLR
0x40020060 GP1TGL
0x40020064 GP1POL
0x40020068 GP1IENA
0x4002006C GP1IENB
0x40020070 GP1INT
0x40020074 GP1DS
0x40020080 GP2CON
0x40020084 GP2OEN
0x40020088 GP2PE
0x4002008C GP2IEN
0x40020090 GP2IN
0x40020094 GP2OUT
0x40020098 GP2SET
0x4002009C GP2CLR
0x400200A0 GP2TGL
0x400200A4 GP2POL
0x400200A8 GP2IENA
0x400200AC GP2IENB
0x400200B0 GP2INT
0x400200B4 GP2DS
Description
GPIO Port 0 configuration
GPIO Port 0 output enable
GPIO Port 0 input/output pull-up enable
GPIO Port 0 input path enable
GPIO Port 0 registered data input
GPIO Port 0 data output
GPIO Port 0 data output set
GPIO Port 0 data output clear
GPIO Port 0 pin toggle
GPIO Port 0 interrupt polarity
GPIO Port 0 Interrupt A enable
GPIO Port 0 Interrupt B enable
GPIO Port 0 interrupt status
GPIO Port 0 drive strength select
GPIO Port 1 configuration
GPIO Port 1 output enable
GPIO Port 1 input/output pull-up enable
GPIO Port 1 input path enable
GPIO Port 1 registered data input
GPIO Port 1 data output
GPIO Port 1 data output set
GPIO Port 1 data output clear
GPIO Port 1 pin toggle
GPIO Port 1 interrupt polarity
GPIO Port 1 Interrupt A enable
GPIO Port 1 Interrupt B enable
GPIO Port 1 interrupt status
GPIO Port 1 drive strength select
GPIO Port 2 configuration
GPIO Port 2 output enable
GPIO Port 2 input/output pull-up enable
GPIO Port 2 input path enable
GPIO Port 2 registered data input
GPIO Port 2 data output
GPIO Port 2 data output set
GPIO Port 2 data output clear
GPIO Port 2 pin toggle
GPIO Port 2 interrupt polarity
GPIO Port 2 Interrupt A enable
GPIO Port 2 Interrupt B enable
GPIO Port 2 interrupt status
GPIO Port 2 drive strength select
Rev. B | Page 218 of 312
ADuCM355 Hardware Reference Manual
Reset Access
0x00000000 R/W
0x0000 R/W
0x2 R/W
0x0000 R/W
0xXXXX R
0x0000 R/W
0x0000 W
0x0000 W
0x0000 W
0x0000 R/W
0x0000 R/W
0x0000 R/W
0x43C0 R/W
0x0000 R/W
0x00000000 R/W
0x0000 R/W
0x0002 R/W
0x0002 R/W
0xXXXX R
0x0000 R/W
0x0000 W
0x0000 W
0x0000 W
0x0000 R/W
0x0000 R/W
0x0000 R/W
0x7800 R/W
0x0000 R/W
0x00000000 R/W
0x0000 R/W
0x0000 R/W
0x0000 R/W
0x0XXX R
0x0000 R/W
0x0000 W
0x0000 W
0x0000 W
0x0000 R/W
0x0000 R/W
0x0000 R/W
0x4 R/W
0x0000 R/W
