INPUT DATA BITS REGISTER

Address: 0x40040010 to 0x40040017 (Increments of 0x01), Reset: 0x00, Name: IPBITSN
Table 409. Bit Descriptions for IPBITSN
Bits Bit Name Settings
[7:0] DATA_BITS

INPUT DATA BYTE REGISTER

Address: 0x40040010, Reset: 0x00, Name: IPBYTE
Table 410. Bit Descriptions for IPBYTE
Bits Bit Name Settings
[7:0] DATA_BYTE
Description
Input Data Bits. These fields are used to calculate CRC data byte from 1 bit to 7 bits of
input data. Computing CRC on x bits of input data can be achieved by writing the byte
to Bit x of this register.
Description
Input Data Byte. Writing data to this field calculates CRC on a byte of data.
Rev. B | Page 310 of 312
ADuCM355 Hardware Reference Manual
Reset Access
0x0 W
Reset Access
0x0 W
