Tx SWITCH MATRIX FULL CONFIGURATION REGISTER

Address: 0x400C215C, Reset: 0x00000000, Name: TSWFULLCON
This register allows individual control of the Tx switches. The bit names are the same as the switch names shown in Figure 27.
Note that SWCON, Bit 16 must be set to 1 after writing to this register for the new switch settings to take effect.
Table 148. Bit Descriptions for TSWFULLCON
Bits Bit Name Settings
[31:12] Reserved
11 TR1
10 T11
9 T10
8 T9
7 T8
6 T7
5 T6
4 T5
3 T4
2 T3
1 T2
0 T1
Description
Reserved.
Control of TR1 Switch. Connects the RCAL1 pin to the high speed TIA inverting input.
0 Switch open.
1 Switch closed.
Control of T11 Switch. Connects the DE1 pin to the high speed TIA inverting input.
0 Switch open.
1 Switch closed.
Control of T10 Switch. Connects the DE0 pin to the high speed TIA inverting input.
0 Switch open.
1 Switch closed.
Control of T9 Switch. Used in conjunction with T10 and T11.
0 Switch open. When open, the high speed TIA inverting input can be DE0 or DE1 via
T10 and T11.
1 Switch closed. Ensure T10 and T11 are open. The high speed TIA inverting input is
determined by T1, T2, T3, T4, T5, and T7.
Control of T8 Switch. Allows connection of the R
calibrate the R resistor.
TIA2_05
0 Switch open.
1 Switch closed.
Control of T7 Switch. Connects high speed TIA inverting input to the SE1 pin via T9
and R .
LOAD04
0 Switch open.
1 Switch closed.
Control of T6 Switch. Allows connection of the R
calibrate the R and R
LOAD03
0 Switch open.
1 Switch closed.
Control of T5 Switch. Connects high speed TIA inverting input to the SE0 pin via T9
and R .
LOAD02
0 Switch open.
1 Switch closed.
Control of T4 Switch. Connects high speed TIA inverting input to the
AIN3/BUF_VREF1V8 pin via T9.
0 Switch open.
1 Switch closed.
Control of T3 Switch. Connects high speed TIA inverting input to the AIN2 pin via T9.
0 Switch open.
1 Switch closed.
Control of T2 Switch. Connects high speed TIA inverting input to the AIN1 pin via T9.
0 Switch open.
1 Switch closed.
Control of T1 Switch. Connects high speed TIA inverting input to the AIN0 pin via T9.
0 Switch open.
1 Switch closed.
path onto the DE1 input to
CAL
path on to the DE0 input to
CAL
resistors.
TIA2_03
Rev. B | Page 125 of 312
UG-1262
Reset Access
0x0 R
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
