CONTROL 1 REGISTER

Address: 0x40001428, Reset: 0x01E0, Name: CR1
This register is a secondary control register that expands the level of WUT control, which is provided by CR0.
CR1 allows additional sticky interrupt sources in SR2 to be enabled. These sources fan into the WUT peripheral interrupt to optionally
tell the CPU when the WUT count has changed, when a prescaled (modulo 1) gated clock event has occurred to advance the WUT
count, when a trim boundary has occurred, when the 32-bit WUT count in CNT1 or CNT0 has rolled over, and when the modulo 60
version of the WUT count has rolled over.
Table 388. Bit Descriptions for CR1
Bits Bit Name
[15:9] Reserved
[8:5] PRESCALE2EXP
4 CNTMOD60ROLLINTEN
3 CNTROLLINTEN
2 Reserved
1 PSINTEN
0 CNTINTEN
Settings Description
Reserved.
Prescale Power of Two Division Factor for the WUT Base Clock. PRESCALE2EXP
defines the power of two by which the WUT base clock (nominally 32 kHz)
is prescaled before being used to count time by advancing the contents
of the CNT1 and CNT0 MMRs. In contrast, RTC1 can prescale the clock by
any power of two in the interval Bits[15:0] to use as its time base.
0000 Prescale the WUT base clock by 2
0001 Prescale the WUT base clock by 2
0010 Prescale the WUT base clock by 2
0011 Prescale the WUT base clock by 2
0100 Prescale the WUT base clock by 2
0101 Prescale the WUT base clock by 2
0110 Prescale the WUT base clock by 2
0111 Prescale the WUT base clock by 2
1000 Prescale the WUT base clock by 2
1001 Prescale the WUT base clock by 2
1010 Prescale the WUT base clock by 2
1011 Prescale the WUT base clock by 2
1100 Prescale the WUT base clock by 2
1101 Prescale the WUT base clock by 2
1110 Prescale the WUT base clock by 2
1111 Prescale the WUT base clock by 2
Enable for the WUT Modulo 60 Count Roll Over Interrupt Source,
CNTMOD60ROLLINT in SR2.
0 Disable CNTMOD60ROLLINT interrupt.
1 Enable CNTMOD60ROLLINT interrupt.
Enable CNTROLLINT in SR2 for the WUT Count Roll Over Interrupt Source.
0 Disable CNTROLLINT as an indicator of the WUT peripheral interrupt.
1 Enable CNTROLLINT as an indicator of the WUT peripheral interrupt.
Reserved.
Enable for the Prescaled Modulo 1 Interrupt Source PSINT in SR2.
0 Disable PSINT in SR2 as an indicator of the WUT peripheral interrupt.
1 Enable PSINT in SR2 as an indicator of the WUT peripheral interrupt.
Enable for the WUT Count Interrupt Source, CNTINT in SR2.
0 Disable CNTINT in SR2 as an indicator of the WUT peripheral interrupt.
1 Enable CNTINT in SR2 as an indicator of the WUT peripheral interrupt.
Rev. B | Page 297 of 312
0 = 1.
1
= 2.
2
= 4.
3
= 8.
4
= 16.
5
= 32.
6
= 64.
7
= 128.
8
= 256.
9
= 512.
10
= 1024.
11
= 2048.
12
= 4096.
13 = 8192.
14
= 16384.
15
= 32768.
UG-1262
Reset Access
0x0 R
0xF R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
