Serial Wire Debug Interface - Analog Devices ADuCM355 Hardware Reference Manual

UG-1262

SERIAL WIRE DEBUG INTERFACE

The SWD interface provides a debug port for pin limited packages. The SWD replaces the 5-pin JTAG port with the SWCLK pin and a
single bidirectional data pin (SWDIO), providing all the normal JTAG debug and test functionality. SWDIO and SWCLK are overlaid on
the TMS and TCK pins, respectively, on the Arm 20-pin JTAG interface (see Figure 68).
Table 411. SWD Connections
Signal Connection
SWDIO Data input/output pin. Use a 100 kΩ pull-up resistor to V
SWO No connect.
SWCLK Clock pin. Use a 100 kΩ pull-up resistor to V
V Positive supply voltage. Power supply for JTAG interface drivers.
CC
GND Digital ground.
RESET No connect.
NYU No connect, not used.
