UG-1262

CLOCK SELECT REGISTER

Address: 0x400C0414, Reset: 0x0000, Name: CLKSEL
Table 13. Bit Descriptions for CLKSEL
Bits Bit Name Settings
[15:4] Reserved
[3:2] ADCCLKSEL
[1:0] SYSCLKSEL

GPIO CLOCK MUX SELECT TO GPIO1 PIN REGISTER

Address: 0x400C041C, Reset: 0x0000, Name: GPIOCLKMUXSEL
Select which digital clock is output to GPIO1 for observation.
Table 14. Bit Descriptions for GPIOCLKMUXSEL
Bits Bit Name
[15:3] Reserved
[2:0] SEL

KEY PROTECTION FOR CLKCON0 REGISTER

Address: 0x400C0420, Reset: 0x0000, Name: CLKCON0KEY
This register provides key protection for the CLKCON0 register.
Table 15. Bit Descriptions for CLKCON0KEY
Bits Bit Name Settings
[15:0] KEY
Description
Reserved.
Select ADC Clock Source. To configure the GPIO1 pin for an external clock,
pADI_AGPIO2->CON |= 3<<2;
1<<1; //AGPIO2.1(PWM1) input
0 Internal high frequency oscillator clock.
1 External high frequency crystal (XTAL) clock.
10 Internal low frequency oscillator clock. Not recommended.
11 External clock.
Select System Clock Source. To configure the GPIO1 pin for an external clock,
pADI_AGPIO2->CON |= 3<<2;
1<<1; //AGPIO2.1(PWM1) input
0 Internal high frequency oscillator clock.
1 External high frequency XTAL clock.
10 Internal low frequency oscillator clock. Not recommended.
11 External clock.
Settings Description
Reserved.
Configure Clock Mux Out to GPIO1.
0 System clock.
1 Power gate low frequency clock.
10 PCLK.
11 Wake-up timer (WUT) on analog die clock.
100 GPT0 clock.
101 GPT1 clock.
110 ADC clock.
111 ADC control clock.
Description
Key to Allow Read and Write Access to the CLKCON0 Register. Write 0xA815 to
this register before accessing CLKCON0.
ADuCM355
// EXT_CLK pADI_AGPIO2->IEN |=
// EXT_CLK pADI_AGPIO2->IEN |=
Rev. B | Page 22 of 312
Hardware Reference Manual
Reset
0x0
0x0
Reset Access
0x0 R
0x0 R/W
0x0 R/W
Access
R
R/W
Reset Access
0x0 W
