CHANNEL SOURCE ADDRESS DECREMENT ENABLE CLEAR REGISTER

Address: 0x40010814, Reset: 0x00000000, Name: SRCADDR_CLR
Table 216. Bit Descriptions for SRCADDR_CLR
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN

CHANNEL DESTINATION ADDRESS DECREMENT ENABLE SET REGISTER

Address: 0x40010818, Reset: 0x00000000, Name: DSTADDR_SET
Table 217. Bit Descriptions for DSTADDR_SET
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN

CHANNEL DESTINATION ADDRESS DECREMENT ENABLE CLEAR REGISTER

Address: 0x4001081C, Reset: 0x00000000, Name: DSTADDR_CLR
Table 218. Bit Descriptions for DSTADDR_CLR
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN
Description
Reserved.
Disable Source Address Decrement. This register enables the user to configure a
DMA channel to use the default source address in increment mode. Each bit of
the register represents the corresponding channel number in the DMA controller.
Bit 0 corresponds to DMA Channel 0. Bit M − 1 corresponds to DMA Channel M – 1.
0 No effect. Use the SRCADDR_SET register to enable source address decrement on
Channel C.
1 Disables address source decrement on Channel C.
Description
Reserved.
Destination Address Decrement Status and Configure Destination Address
Decrement. The DSTADDR_SET register is used to configure the destination
address of a DMA channel to decrement the address instead of incrementing the
address after each access. Each bit of the register represents the corresponding
channel number in the DMA controller. Bit 0 corresponds to DMA Channel 0.
Bit M − 1 corresponds to DMA Channel M – 1.
0 When read as 0, Channel C destination address decrement is disabled. When
written as 0, no effect. Use the DSTADDR_CLR register to disable destination
address decrement on Channel C.
1 When read as 1, Channel C destination address decrement is enabled. When
written as 1, destination address decrement on Channel C is enabled.
Description
Reserved.
Disable Destination Address Decrement. This register enables the user to
configure a DMA channel to use the default destination address in increment
mode. Each bit of the register represents the corresponding channel number in
the DMA controller. Bit 0 corresponds to DMA Channel 0. Bit M − 1 corresponds
to DMA Channel M – 1.
No effect. Use the DSTADDR_SET register to enable destination address
0
decrement on Channel C.
1 Disables destination address decrement on Channel C.
Rev. B | Page 183 of 312
UG-1262
Reset Access
0x00 R
0x000000 W
Reset Access
0x00 R
0x000000 R/W
Reset Access
0x00 R
0x000000 W
