Bits Bit Name Settings
25 FLAG25
24 FLAG24
23 FLAG23
[22:18] Reserved
17 FLAG17
16 FLAG16
15 FLAG15
14 Reserved
13 FLAG13
12 FLAG12
11 FLAG11
10 FLAG10
9 FLAG9
8 Reserved
7 FLAG7
6 FLAG6
5 FLAG5
Description
Data FIFO Threshold IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Data FIFO Empty IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Data FIFO Full IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Reserved.
Sequencer Timeout Error IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Sequencer Timeout Finished IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
End of Sequence IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Reserved.
Bootload Done IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Custom Interrupt 3 Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Custom Interrupt 2 Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Custom Interrupt 1 Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Custom Interrupt 0 Status.
0 Interrupt not asserted.
1 Interrupt asserted.
Reserved.
Mean IRQ Status.
0 Interrupt not asserted.
1 Interrupt asserted.
ADC Delta Fail IRQ Status. When this bit is set, it indicates that the difference between two
consecutive ADC results is greater than the value specified by the ADCDELTA register. If
this bit is clear, it indicates that no difference between two consecutive ADC values
greater than the limit is detected since the last time this bit was cleared.
0 Interrupt not asserted.
1 Interrupt asserted.
ADC Maximum Fail IRQ Status. When this bit is set, it indicates that an ADC result is
above the maximum value specified by the ADCMAX register. If this bit is clear, it
indicates that no ADC value above the maximum is detected.
0 Interrupt not asserted.
1 Interrupt asserted.
Rev. B | Page 143 of 312
UG-1262
Reset Access
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
