16-BIT ASYNCHRONOUS LOAD VALUE REGISTERS

Address: 0x40000014, Reset: 0x0000, Name: GPT0_ALOAD
Address: 0x40000414, Reset: 0x0000, Name: GPT1_ALOAD
Address: 0x40000814, Reset: 0x0000, Name: GPT2_ALOAD
Table 348. Bit Descriptions for GPT0_ALOAD, GPT1_ALOAD, GPT2_ALOAD
Bits Bit Name Settings
[15:0] VALUE

16-BIT TIMER ASYNCHRONOUS VALUE REGISTERS

Address: 0x40000018, Reset: 0x0000, Name: GPT0_ACURCNT
Address: 0x40000418, Reset: 0x0000, Name: GPT1_ACURCNT
Address: 0x40000818, Reset: 0x0000, Name: GPT2_ACURCNT
Table 349. Bit Descriptions for GPT0_ACURCNT, GPT1_ACURCNT, GPT2_ACURCNT
Bits Bit Name Settings
[15:0] VALUE

STATUS REGISTERS

Address: 0x4000001C, Reset: 0x0000, Name: GPT0_STAT
Address: 0x4000041C, Reset: 0x0000, Name: GPT1_STAT
Address: 0x4000081C, Reset: 0x0000, Name: GPT2_STAT
Table 350. Bit Descriptions for GPT0_STAT, GPT1_STAT, GPT2_STAT
Bits Bit Name Settings
[15:8] Reserved
7 PDOK
6 BUSY
[5:2] Reserved
1 CAPTURE
0 TIMEOUT
Description
16-Bit Captured Value. GPTx_CAPTURE holds its value until GPTx_CLRINT, Bit 1 is set by user
code. GPTx_CAPTURE is not overwritten even if another event occurs without writing to
GPTx_CLRINT, Bit 1. Only use when a synchronous clock source is selected (GPTx_CTL,
Bits[6:5] = 00 or if the high frequency oscillator is clocking both the timer and CPU directly).
Description
Counter Value. Reflects the current up or down counter value. Reading GPTx_ACURCNT
takes advantage of having the timer run on PCLK by bypassing clock synchronization
logic that is otherwise required. Only use when a synchronous clock source is selected
(GPTx_CTL, Bits[6:5] = 00 or if the high frequency oscillator is clocking both the timer
and CPU directly).
Description
Reserved.
GPTx_CLRINT Synchronization. This bit is set automatically when the user sets GPTx_CLRINT,
Bit 0 = 1. This bit is cleared automatically when the clear interrupt request has crossed
clock domains and taken effect in the timer clock domain.
0 The interrupt is cleared in the timer clock domain.
1 GPTx_CLRINT, Bit 0 is being updated in the timer clock domain.
Timer Busy. This bit informs the user that a write to GPTx_CTL is still crossing into the
timer clock domain. Check this bit after writing GPTx_CTL and suppress further writes
until this bit is cleared.
0 Timer ready to receive commands to GPTx_CTL.
1 Timer not ready to receive commands to GPTx_CTL.
Reserved.
Capture Event Pending.
0 No capture event is pending.
1 A capture event is pending.
Timeout Event Occurred. This bit is set automatically when the value of the counter
reaches zero while counting down or reaches full scale when counting up. This bit is
cleared when GPTx_CLRINT, Bit 0 is set by the user.
0 No timeout event has occurred.
1 A timeout event has occurred.
