3.3.7 Inspecting, cable harness

3.3.7 Inspecting, cable harness
Location of cable harness, axes 1-6
The axes-1-6 cable harness is shown below.
The figure shows the lower routing of the cable harness.
xx0600002970
A
B
C
D
E
F
G
H
Continues on next page
130
SMB/BU box
Top cover, connection box
Connection plate, base
Connector R1.SMB
Connector R1.MP
Metal clamps
Cable harness
Cable guide (cut away view)
