reactor is configured.
3. The rated output voltage drop of output reactors is 1%± 15%.
4. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
D.6.2 Reactors for AC 3PH 520 V (-15%)–690 V (+10%)
VFD power
GD35-022-6-C1/D1/H1
GD35-030-6-C1/D1/H1
GD35-037-6-C1/D1/H1
GD35-045-6-C1/D1/H1
GD35-055-6-C1/D1/H1
GD35-075-6-C1/D1/H1
GD35-090-6-C1/D1/H1
GD35-110-6-C1/D1/H1
GD35-132-6-C1/D1/H1
GD35-160-6-C1/D1/H1
GD35-185-6-C1/D1/H1
GD35-200-6-C1/D1/H1
GD35-220-6-C1/D1/H1
GD35-250-6-C1/D1/H1
GD35-280-6-C1/D1/H1
GD35-315-6-C1/D1/H1
GD35-350-6-C1/D1/H1
GD35-400-6-C1/D1/H1
GD35-500-6-C1/D1/H1
GD35-560-6-C1/D1/H1
GD35-630-6-C1/D1/H1
Note:
1. The rated input voltage drop of input reactors is 2%±15%.
2. The current adjustment coefficient on the input side of the VFD is higher than 90% after a DC
reactor is configured.
3. The rated output voltage drop of output reactors is 1%± 15%.
4. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
D.7 Filter
J10 is not connected in factory for VFDs of 380V (≤110kW). Connect the J10 packaged with the
manual if the requirements of level C3 need to be met.
Input reactor
ACL2-030G-6
ACL2-030G-6
ACL2-055G-6
ACL2-055G-6
ACL2-055G-6
ACL2-110G-6
ACL2-110G-6
ACL2-110G-6
ACL2-185G-6
ACL2-185G-6
ACL2-185G-6
ACL2-250G-6
ACL2-250G-6
ACL2-250G-6
ACL2-350G-6
ACL2-350G-6
ACL2-350G-6
Standard configuration
Standard configuration
Standard configuration
Standard configuration
281
Optional peripheral accessories
DC reactor Output reactor
DCL2-030G-6 OCL2-030G-6
DCL2-030G-6 OCL2-030G-6
DCL2-055G-6 OCL2-055G-6
DCL2-055G-6 OCL2-055G-6
DCL2-055G-6 OCL2-055G-6
DCL2110G-6 OCL2-110G-6
DCL2-110G-6 OCL2-110G-6
DCL2-110G-6 OCL2-110G-6
DCL2-185G-6 OCL2-185G-6
DCL2-185G-6 OCL2-185G-6
DCL2-185G-6 OCL2-185G-6
DCL2-250G-6 OCL2-250G-6
DCL2-250G-6 OCL2-250G-6
DCL2-250G-6 OCL2-250G-6
DCL2-350G-6 OCL2-350G-6
DCL2-350G-6 OCL2-350G-6
DCL2-350G-6 OCL2-350G-6
DCL2-400G-6 OCL2-400G-6
DCL2-560G-6 OCL2-560G-6
DCL2-560G-6 OCL2-560G-6
DCL2-630G-6 OCL2-630G-6
