INVT Goodrive35 Series Operation Manual page 119

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Source current 2
P13.03
Shift frequency of
P13.04
source current
P13.05 Reserved
High-frequency
P13.06
superposing voltage
Control parameter 0 0.0–400.0%
P13.07
Control parameter 1 0x0000–0xFFFF
P13.08
Control parameter 2 0.00–655.35
P13.09
Initial angle
compensation of
P13.10
synchronous
machine
Maladjustment
P13.11
detection time
High-frequency
compensation
coefficient of
P13.12
synchronous
machine
Brake current of
P13.13
short-circuit
Brake retention time
P13.14
before starting
The brake retention
P13.15
time when stopping
Detailed instruction of parameters
motor)
Source current is directional current of the magnetic
pole position. Source current 2 is valid under the
frequency point of current shifting. There is no need
to modify the value generally.
Setting range: 0.0%–100.0% (rated current of motor)
0.0%–80.0% (max frequency)
0.0–300.0% (rated voltage of the motor)
0.0–359.9
Adjust the response of anti-maladjustment. Bigger
load inertia may increase the value, but the response
will be slower.
Setting range: 0.0–10.0 s
When the motor speed is faster than the rated
speed, the parameter is valid, if vibration occurs to
the motor, please adjust the parameter.
Setting range: 0.0–100.0%
When P01.00=0 during the starting of the VFD, set
P13.14 to a non-zero value to enter the short circuit
brake.
When the running frequency is lower than P01.09
during the stopping of the VFD, set 13.15 to a
non-zero value to enter into stopping short circuited
brake and then carry out the DC brake at the time
set by P01.12
P01.09–P01.12) .
Setting range of P13.13: 0.0–150.0% (the VFD)
Setting range of P13.14: 0.0–50.0s
Setting range of 13.15: 0.0–50.0s
112
(refer to the instruction
Function parameters
Default Modif
value y
10.0%
○
20.0%
○
100.0%
◎
0.0%
○
0x0000
○
2.00
○
0.0
○
0.5 s
○
0.0% ○
0.0%
○
0.0 s
○
of
0.0 s
○
