C.4 Dimensions for VFDs of AC 3PH 380 V (-15%)–440 V (+10%)
C.4.1 Wall installation (unit: mm)
Model
1.5 kW–2.2 kW
4 kW–5.5 kW
7.5 kW–11 kW
15 kW–18.5 kW
22 kW–30 kW
Model
37 kW–55 kW
75 kW–110 kW
Figure C-3 Wall installation of 380 V 1.5-30 kW VFDs
W1 W2 H1
126 115 193
146 131 263
170 151 331.5
230 210 342
255 237 407
Figure C-4 Wall installation of 380 V 37-110 kW VFDs
W1 W2 H1
270 130 555
325 200 680
H2 D1
175 174.5
243.5 181
303.5 216
311 216
384 245
H2 D1
540 325
661 365
262
Dimension drawings
Installation Weight
hole (kg)
5 2
6 3.5
6 6
6 7.8
7 9.5
Installation Weight
hole (kg)
7 30
9.5 47
