Goodrive35 Series Closed-loop Vector Control VFD
Set value
20 Multi-step speed pause
21 ACC/DEC time selection 1 Select 4 ACC/DEC time by the combination of the 2
22 ACC/DEC time selection 2
23 Simple PLC stop reset
24 Simple PLC pause
25 PID control pause
26 Limit of forward run
27 Limit of reverse run
28 Counter reset
29 Torque control disabling
30 ACC/DEC disabling
31 Counter trigging
32
33 increasing/decreasing
setting temporal clear
Function
Length reset
Frequency
Multi-step Multi-step
speed 4 speed 3
BIT3
Shield the multi-step speed selection terminal function to
keep the setting value at the current state.
terminals.
Terminal Terminal
1 2
OFF OFF
ON OFF
OFF ON
ON ON
Restart simple PLC and clear memory state of PLC.
Program pause during PLC implement. Run at the current
speed stage. After cancel the function, simple PLC
continues to run.
Temporal PID invalid and the VFD will output at the current
frequency.
The function is valid only for forward run.
The function is valid only for reverse run.
Counter clear
The VFD shifts from torque control mode to speed control
mode.
Ensure the VFD will not be affected by the external signals
(except for the stopping command) and keep the current
output frequency.
Enable the pulse counter.
Length counter clear
When the terminal closes, the frequency set by UP/DOWN
can be cleared. All set frequency will be restored into the
given frequency by the frequency command channel and
the frequency will come back to the value after the
frequency increasing or decreasing.
172
Basic operation instruction
Instructions
Multi-step
speed 2
BIT2 BIT1
ACC/DEC Corresponding
time selection
ACC/DEC time
P00.11/P00.12
1
ACC/DEC time
P08.00/P08.01
2
ACC/DEC time
P08.02/P08.03
3
ACC/DEC time
P08.04/P08.05
4
Multi-step
speed 1
BIT0
parameter
