Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
P05.07 S7 terminal function
P05.08 S8 terminal function
P05.09 HDI terminal function
Detailed instruction of parameters
15: Shift between combination setting and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Forward rotation limit
27: Reverse rotation limit
28: Electronic gear selection
29: Torque control disabling
30: ACC/DEC disabling
31: Pulse ascending
32: Pulse descending
33: Cancel the frequency change setting temporarily
34: DC brake
35: Shift the motor 1 into motor 2
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Consumption power clear
41: Consumption power holding
42: Keypad setting of the torque upper limit
43: Position reference input (only S8 valid)
44: Spindle direction prohibit
45: Spindle returning /Local position returning
46: Zero position selection 1
47: Zero position selection 2
48: Spindle scaling selection 1
49: Spindle scaling selection 2
50: Spindle scaling selection 3/Pulse superposition
enabling
51: Switching terminal of position control and speed
73
Function parameters
Default Modif
value y
0 ◎
0
◎
0 ◎
