INVT Goodrive35 Series Operation Manual page 157

Goodrive35 Series Closed-loop Vector Control VFD
Function
code
P03.12 Keypad setting torque -300.0%–300.0% (rated current of the motor)
Torque reference filter
P03.13
Upper frequency of
P03.14 forward rotation in
vector control
Upper frequency of
P03.15 reverse rotation in
vector control
Keypad setting for
P03.16 upper frequency of
forward rotation
P03.17 Keypad setting for
Name
7: Modbus communication setting torque (the
same as above)
8:
setting torque (the same as above)
9: Ethernet communication setting torque (the
same as above)
10: Reserved
0.000–10.000 s
time
0: Keypad (P03.16)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDI (the same as above)
5: Multi-step (the same as above)
6: Modbus communication (the same as
above)
7: PROFIBUS/CANopen communication (the
same as above)
8: Ethernet communication (the same as
above)
0: Keypad (P03.17)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDI (the same as above)
5: Multi-step (the same as above)
6: Modbus communication (the same as
above)
7: PROFIBUS/CANopen communication (the
same as above)
8: Ethernet communication (the same as
above)
0.00 Hz–P00.03 (max. output frequency)
0.00 Hz–P00.03 (max. output frequency)
Detailed instruction of parameters
PROFIBUS/CANopen
150
Basic operation instruction
Default
value
communication
10.0%
0.100s
50.00 Hz
50.00 Hz
0
0
