2.1 What this chapter contains

This chapter mainly describes the basic guidelines during the installation and commission procedures
on the VFD, which you may follow to install and commission the VFD quickly.

2.2 Unpacking inspection

Check as followings after receiving products:
1. Check that there are no damage and humidification to the package. If not, please contact with
local agents or company offices.
2. Check the information on the type designation label on the outside of the package to verify
that the drive is of the correct type. If not, please contact with local dealers or company offices.
3. Check that there are no signs of water in the package and no signs of damage or breach to
the VFD. If not, please contact with local dealers or company offices.
4. Check the information on the type designation label on the outside of the package to verify
that the name plate is of the correct type. If not, please contact with local dealers or company
offices.
5. Check to ensure the accessories (including user's manual, control keypad and extension
card) inside the device is complete. If not, please contact with local dealers or company offices.

2.3 Application confirmation

Check the machine before beginning to use the VFD:
1. Check the load type to verify that there is no overload of the VFD during work and check that
whether the drive needs to modify the power degree.
2. Check that the actual current of the motor is less than the rated current of the VFD.
3. Check that the control accuracy of the load is the same of the VFD.
4. Check that the incoming supply voltage is correspondent to the rated voltage of the VFD.
5. Check that the communication needs option card or not.

2.4 Environment

Check as followings before the actual installation and usage:
1. Check that the ambient temperature of the VFD is below 40° C. If exceeds, derate 1% for
every additional 1° C. Additionally, the VFD cannot be used if the ambient temperature is above
50° C.
Note: for the cabinet VFD, the ambient temperature means the air temperature inside the
cabinet.
2. Check that the ambient temperature of the VFD in actual usage is above -10° C. If not, add
heating facilities.
Note: for the cabinet VFD, the ambient temperature means the air temperature inside the
cabinet.
3. When the altitude exceeds 1000m but is lower than 3000m, derate 1% for every additional
